E+H CPA250-A00 Flow Assembly Flowfit
Product Details:
Manufacturer : Endress+Hauser
Product No. : PMD75-11038/139
https://www.achievers-automation.com More Products
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The E+H PMD75-11038/139 is a high-precision differential pressure transmitter belonging to (E+H) Deltabar PMD75 series, engineered for continuous measurement of pressure differences in liquids, vapors, and gases across diverse industrial sectors. As a globally trusted manufacturer of process measurement and automation solutions, E+H designs the PMD75-11038/139 with a piezoresistive sensor and welded metallic membrane, ensuring exceptional accuracy, long-term stability, and reliability in harsh industrial environments. This page provides detailed technical specifications, core features, and application insights to help engineers and technical professionals make informed selection decisions, aligned with industry best practices and Google SEO standards.
Detail:
|
Specification Category
|
Details for E+H PMD75-11038/139
|
|
Sensor Type
|
Piezoresistive Sensor with Welded Metallic Membrane
|
|
Process Membrane Material
|
316L Stainless Steel, Alloy C276, Tantalum, Gold-Rhodium
|
|
Main Wetted Parts
|
Alloy C276, 316L Stainless Steel, Monel, Tantalum
|
|
Pressure Measuring Range
|
0.25 mbar to 40 bar (0.0036 psi to 600 psi)
|
|
Overload Resistance
|
Up to 420 bar (42 MPa / 6300 psi)
|
|
Process Connections
|
Threaded Connections
|
|
Enclosure Protection Rating
|
IP67 (NEMA 4X)
|
|
Vibration Resistance
|
10 g (10-2000 Hz), 50 g (6 ms shock)
|
|
Weight (Approx.)
|
1.2 kg (2.65 lbs) without process connections
|
|
Installation Position
|
Any position; recommended: membrane horizontal
|
|
Process Temperature Range
|
-40 °C to +85 °C (-40 °F to +185 °F)
|
|
Humidity Range
|
0-100% RH (non-condensing)
|
|
Specification Category
|
Details for E+H PMD75-11038/139
|
|
Product Model
|
PMD75-11038/139
|
|
Manufacturer
|
Endress+Hauser (E+H)
|
|
Product Series
|
Deltabar PMD75
|
|
Device Type
|
Differential Pressure Transmitter
|
|
Standards Compliance
|
IEC 61508 (SIL 2/3), International Explosion Protection Standards
|
|
Accuracy (Standard)
|
±0.05%
|
|
Accuracy (Platinum, Optional)
|
±0.035%
|
|
Output Signal
|
4-20 mA with HART, Profibus PA, Foundation Fieldbus
|
|
Power Supply
|
12-45 VDC (HART); 9-32 VDC (Profibus PA); 12-45 VDC (Foundation Fieldbus)
|
|
Operating Temperature (Electronics)
|
-40 °C to +85 °C (-40 °F to +185 °F)
|
|
Storage Temperature
|
-40 °C to +100 °C (-40 °F to +212 °F)
|
|
Certifications
|
Explosion Protection, WHG Overfill Prevention, Hygienic Approvals, Marine Approvals
|
Brand
E+H is a global leader in providing measurement instruments, services, and solutions for the process and laboratory industries. Since its founding in 1953, the company has been committed to enhancing production efficiency, safety, and sustainability through innovative technologies. E+H’s product portfolio covers a wide range of areas, including flow measurement, level measurement, pressure and temperature measurement, analytical instrumentation, and data management. Its solutions are widely used in industries such as chemicals, food and beverage, oil and gas, power generation, and water and wastewater treatment.
